Wavebar dBX

dBX flexible noise barrier

This high performing product was engineered by Pyrotek to achieve a self-extinguishing, low smoke emission, thin, strong and highly flexible solution.

Stiff lightweight panel constructions, such as plasterboard, drywall, plywood and hollow core walls, typically have coincidence dip resonance which allows noise to transmit through a construction. The coincidence dip is dependent on the material’s stiffness and thickness and occurs at the point where the sound transmitted through the structure matches the natural frequency of the panel.

dBX shifts the coincidence dip to frequencies limiting its impact, thereby maintaining the performance of the product. The thin, dense mass barrier reflects and absorbs the transmission of sound through walls, ceilings and floors, reducing the critical frequencies generated from mechanical equipment, engine noise and electronic audio technologies such as radio and television.

Wavebar® dBX

Wavebar® dBX

Technical data

This high performing product was engineered by Pyrotek to achieve a self-extinguishing, low smoke emission, thin, strong and highly flexible solution.

Please refer to the Technical Data Sheet (TDS) for more information.

Document downloads

Document title Document type Document language
Wavebar dBX Technical Data Sheet English
Wavebar Installation (PLENUM SPACE) Installation Guide English
Wavebar Installation (CURTAIN) Installation Guide English
Wavebar and Quadzero Range Brochure English
Wavebar and Quadzero Range (ZH) Brochure 中文 (Chinese)
WP-How noise affects concentration Brochure English

Applications

  • Inside cavities or over lightweight wall, ceiling and floor constructions. Ideal for theatres, office partitions, meeting rooms and high privacy areas
  • Between the plenum chamber of a floor slab, roof and adjoining partition walls
  • Acoustic doors to increase transmission loss
  • Automotive cabin application to reduce engine and road noise transmitting through the structure
  • Usable where moulded parts or components are required

Features

  • Thermo-formable into different shapes
  • Self-extinguishes upon removal of flame, does not drip
  • Resistant to water, oil and natural weather conditions
  • Free from lead, odour-producing oils, halogens and bitumen
  • No ozone-depleting substances generated during manufacture
  • Tear-resistant with high tensile strength
  • Simple to cut, tape and mechanically fasten into position
